13
Other Information
Specifications
Display Type
Display Size
Color Filter
Glass Surface
TFT (Thin Film Transistor), Active Matrix 1920 x 1080 Display,
0.24825 mm pixel pitch
Metric: 54.6 cm
Imperial: 22” (21.5” viewable)
RGB vertical stripe
Anti-Glare
Input Signal Video Sync RGB analog (0.7/1.0 Vp-p, 75 ohms)
HDMI (TMDS digital, 100ohms)
DisplayPort
Composite Sync, Separate Sync, Sync on Green
f
h
:24-82 kHz, f
v
:50-75 Hz
Compatibility PC
Macintosh
Up to 1920 x 1080 Non-interlaced
Power Macintosh up to 1920 x 1080
Resolution
1
Recommended
Supported
1920 x 1080 @ 60 Hz
1680 x 1050 @ 60 Hz
1440 x 900 @ 60, 75 Hz
1280 x 1024 @ 60, 75 Hz
1024 x 768 @ 60, 70, 75 Hz
800 x 600 @ 56, 60, 72, 75 Hz
640 x 480 @ 60, 67, 72, 75 Hz
720 x 400 @ 70 Hz
Power Voltage 100-240 VAC, 50/60 Hz (auto switch)
Display area Full Scan 476.64mm (H) x 268.11mm (V)
18.77” (H) x 10.56” (V)
Operating
conditions
Temperature
Humidity
Altitude
+32 °F to +104 °F (0 °C to +40 °C)
20% to 90% (non-condensing)
To 10,000 feet
Storage
conditions
Temperature
Humidity
Altitude
-4 °F to +140 °F (-20 °C to +60 °C)
5% to 90% (non-condensing)
To 40,000 feet
Dimensions Physical 490.3mm (W) x 298.9mm (H) x 47.3mm (D) (stand @0 degrees)
19.3” (W) x 11.77” (H) x 1.86” (D)
490.3mm (W) x 287.2mm (H) x 129.7mm (D) (stand @20 degrees)
19.3” (W) x 11.31” (H) x 5.11” (D)
490.3mm (W) x 132.7mm (H) x 283.2mm (D) (stand @70 degrees)
19.3” (W) x 5.22” (H) x 11.15” (D)
Wall Mount Distance
Screw
100 x 100 mm
[M4 x 8mm] x4
Weight Physical 7.9 lb (3.6 kg)
Power saving
modes
On
Off
20W(typical), (Blue LED)
Adaptor source: FSP045-REBN2
<0.5W
1
Do not set the graphics card in your computer to exceed these timing mode; doing so may result in permanent
damage to the display.
2
The test condition follows EEI standard
