ViewSonic TD2230 User Manual

2
Product Registration
To fulfill possible future product needs, and to receive additional product information
as it becomes available, please visit your region section on ViewSonic’s website to
register your product online.
Registering your product will best prepare you for future customer service needs.
Please print this user guide and fill the information in the “For Your Records” section.
Your display serial number is located on the rear side of the display.
For additional information, please see the “Customer Support” section in this guide.
For Your Records
Product Name:
Model Number:
Document Number:
Serial Number:
Purchase Date:
TD2230
ViewSonic Widescreen Display
VS16453
TD2230_UG_ENG_1c_20220124
Proper product disposal is necessary at the end of product life
ViewSonic respects the environment and is committed to working and living green.
Thank you for being part of a Smarter, Greener Computing effort.
Please visit the ViewSonic website to learn more.
USA & Canada:
https://www.viewsonic.com/us/company/green/go-green-with-viewsonic/#recycle-program
Europe:
http://www.viewsoniceurope.com/eu/support/call-desk/
Taiwan:
http://recycle.epa.gov.tw

ViewSonic TD2230 Specifications

General

Panel type	ADS
Pixel pitch	0.24825 x 0.24825 mm
Screen shape	Flat
Display diagonal	21.5 \
Touch technology	Multi-touch
Touchscreen type	Multi-user
Display brightness	250 cd/m²
Display technology	LCD
Vertical scan range	50 - 76 Hz
Maximum refresh rate	76 Hz
Horizontal scan range	24 - 82 kHz
Touchscreen technology	Projected capacitive system
Contrast ratio (dynamic)	50000000:1
Contrast ratio (typical)	1000:1
Display diagonal (metric)	54.6 cm
Supported graphics resolutions	640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1440 x 900 (WXGA+), 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080)
Number of simultaneous touchpoints	10
Certification	cULus, FCC-B, ICES003, Energy Star 8.0, EPEAT Bronze, CEC, MX-CoC, Mexico Energy, CE, CE EMC, CB, RoHS, ErP, REACH, WEEE, EAC, UkrSEPRO, BIS, CCC, China RoHS, China Energy Label, CECP
Product color	Black
Display viewable area (HxV)	476.64 x 268.11 mm
Cables included	AC, Audio (3.5mm), HDMI, USB
Audio input	1
HDMI version	1.4
USB hub version	3.2 Gen 1 (3.1 Gen 1)
DisplayPort version	1.2
USB upstream port type	USB Type-B
USB Type-A downstream ports quantity	2
Tilt angle range	20 - 70 °
Number of OSD languages	12
Panel mounting interface	100 x 100 mm
AC input voltage	100-240 V
Power supply type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	25 W
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	20 - 90 %
Package depth	114 mm
Package width	550 mm
Package height	371 mm
Package weight	4700 g
NVIDIA G-SYNC	No
Other operating systems supported	Android
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1
RMS rated power	6 W
Sustainability certificates	CE, EPEAT Bronze, ErP, REACH, RoHS
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth (with stand)	47 mm
Width (with stand)	490 mm
Height (with stand)	299 mm
Weight (with stand)	3580 g
