ViewSonic VG2740V - Wall Mounting

13
Wall Mounng
Refer to the table below for the standard dimensions for wall mount kits.
NOTE: For use only with a UL Listed Wall Mount Bracket. To obtain a wall-
mounngkitorheightadjustmentbase,contactViewSonic®oryour
local dealer.
Maximum
Loading
Hole paern
(W x H)
Interface Pad
(W x H x D)
Pad Hole
Screw Specicaon &
Quanty
14 kg 100 x 100 mm 115 x 115 x 2.6 mm Ø 5 mm
M4 x 10 mm
4 pieces
NOTE: Wall mount kits are sold separately.
1. Turnothedeviceanddisconnectallcables.
2. Placethedeviceonaat,stablesurfacewiththescreenfacingdown.
3. Pressandholdthequickreleasetabandcarefullylithestand.
4. Pull down slightly to disengage the hooks and remove the stand.
