ViewSonic VG3456C User Manual

48
C
Color Adjust
Provides several color adjustment modes to help adjust the color sengs to
t the user’s needs.
Color Range
The monitor can detect the input signal color range automacally. You can
manually change the color range opons to t the correct color range if the
colors are not displayed correctly.
Opons Descripon
Auto
The monitor automacally recognizes the color format and
black and white levels.
Full Range The color range of the black and white levels are full.
Limited Range The color range of the black and white levels are limited.
Color Space
Allows users to choose which color space they would like to use for monitor
color output (RGB, YUV).
Color Temperature
Allows users to select specic color temperature sengs to further
customize their viewing experience.
Panel Default Panel Original Status
sRGB Standard color space used for the Windows system.
Bluish Set the color temperature to 9300K.
Cool Set the color temperature to 7500K.
Nave Default color temperature. Recommended for general use.
Warm Set the color temperature to 5000K.
Contrast
Adjusts the dierence between the image background (black level) and the
foreground (white level).
G
Gamma
Allows users to manually adjust the brightness level of the monitor’s
grayscale levels. There are six selecons: 1.8, 2.0, 2.2, 2.4, 2.6, and 2.8.
H
Hue
Adjusts the nt of each color (red, green, blue, cyan, magenta, and yellow).

ViewSonic VG3456C Specifications

General

Panel type	VA
Color gamut	86 %
Pixel pitch	0.232 x 0.232 mm
Touchscreen	-
Response time	3.5 ms
Backlight type	LED
Display diagonal	34 \
Surface hardness	3H
Anti-glare screen	Yes
Native aspect ratio	21:9
Maximum refresh rate	120 Hz
Screen curvature rating	1500R
sRGB coverage (typical)	100 %
Contrast ratio (typical)	3000:1
Display number of colors	16.7 million colors
Display diagonal (metric)	86 cm
Display brightness (typical)	300 cd/m²
Dynamic contrast ratio marketing name	Mega Contrast
AC input voltage	100 - 240 V
Power supply type	Internal
Energy efficiency scale	A to G
Power consumption (max)	66 W
Power consumption (standby)	0.3 W
Power consumption (typical)	56 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	20 - 90 %
Package depth	224 mm
Package width	980 mm
Package height	526 mm
Package weight	13500 g
Tilt angle range	-3.5 - 23 °
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
Product color	Black
USB hub version	3.2 Gen 1 (3.1 Gen 1)
DisplayPort version	1.4
USB upstream port type	USB Type-A, USB Type-B, USB Type-C
USB Power Delivery up to	65 W
USB Type-A downstream ports quantity	3
RMS rated power	1 W
Number of speakers	2
AMD FreeSync type	FreeSync Premium

Weight and Dimensions

Depth (with stand)	269 mm
Width (with stand)	809 mm
Height (with stand)	593.8 mm
Weight (with stand)	10600 g
Depth (without stand)	107 mm
Height (without stand)	366 mm
Weight (without stand)	6800 g
