13
Removing the Stand and Mounng the Monitor
Refer to the table below for the standard dimensions for mounng kits.
NOTE: For use only with a UL cered mounng kit/bracket. To obtain a wall
mounng kit or height adjustment base, contact ViewSonic® or your
local dealer.
Maximum
Loading
Hole paern
(W x H)
Interface Pad
(W x H x D)
Pad Hole
Screw
Specicaon
Screw
Quanty
14 kg 100 x 100 mm N/A N/A M4 x 10 mm 4
NOTE: Mounng kits are sold separately.
1. Turn o the monitor, disconnect all cables, and remove the remote control.
2. Place the monitor on a at, stable surface with the screen facing down.
3. Unscrew the captured screw in the monitor stand’s base and remove it from the
monitor stand’s neck.
4. Press and hold the quick release tab and carefully li the stand.
1
2
