17User Manual Visit the ViewZ USA website at https://www.viewzusa.com
2PLRRATIO
2PLRSWAP
DISPLAYFUNCTION
SELECTREGION
INPU T
AUDIOINPU T
ENTER2PLRMODE
CONTROL AND FUNCTION
2P LR (INPUT MODE)
INPUT
DISPLAY FUNCTION
SELECT REGION
2PLR RATIO
2PLR LEFT INPUT
2PLR RIGHT INPUT
2PLR SWAP
ENTER 2PLR MODE
AUDIO INPUT
For select the video source input for dual.
Select the left, right or both area to adjust the monitor setup.
( Region Adjust & SET values).
Set up the large left picture. 0 ( 50:50 aspect ratio ) to
4 ( 75:25 aspect ratio ).
Select the left input source.
Select the right input source.
Swap Left / Right Picture.
Select a display type among 1P, 2PLR, 2PTB, 2P PIP &
4P, if current display mode is not '2PLR'.
Select an audio Input source among two input sources.
VGA / DP / HDMI 1 / HDMI 2
VGA / DP / HDMI 1 / HDMI 2
2PLR FULL / 2PLR LEFT SIDE /
0 ~ 4
2PLR RIGHT SIDE
-
-
2PLR LEFT INPUT /
2PLR RIGHT INPUT
DVI / AUTO
DVI
FUNCTION VALUE
