Viking 24" - Interior Ventilator Dimensions; Exterior Ventilator Dimensions

2120
Exterior Ventilator DimensionsInterior Ventilator Dimensions
A
B
5-1/2”
(14 cm)
10” (25.4 cm)
dia. duct location
A
36”W. 17-15/16” (45.6 cm)
42“W. 20-15/16” (18.2 cm)
54”W. 26-15/16” (68.4 cm)
66”W. 32-15/16” (83.7 cm)
B
36”W. 35-7/8” (91.1 cm)
42“W. 41-7/8” (106.4 cm)
54”W. 53-7/8” (136.8 cm)
66”W. 65-7/8” (167.3 cm)
A
B
7” (17.8 cm)
dia. duct location
4-5/8”
(11.7 cm)
A
36”W. 17-15/16” (45.6 cm)
42“W. 20-15/16” (18.2 cm)
54”W. 26-15/16” (68.4 cm)
66”W. 32-15/16” (83.7 cm)
B
36”W. 35-7/8” (91.1 cm)
42“W. 41-7/8” (106.4 cm)
54”W. 53-7/8” (136.8 cm)
66”W. 65-7/8” (167.3 cm)
600 CFM Interior Ventilator Installation
for all Island Hoods
B
A
5-15/16”
(15.1 cm)
10” (25.4 cm)
dia. duct location
A
36”W. 17-15/16” (45.6 cm)
42“W. 20-15/16” (18.2 cm)
54”W. 26-15/16” (68.4 cm)
66”W. 32-15/16” (83.7 cm)
B
36”W. 35-7/8” (91.1 cm)
42“W. 41-7/8” (106.4 cm)
54”W. 53-7/8” (136.8 cm)
66”W. 65-7/8” (167.3 cm)
A
B
10” (25.4 cm)
dia. duct location
5-15/16”
(15.1 cm)
A
36”W. 17-15/16” (45.6 cm)
42“W. 20-15/16” (18.2 cm)
54”W. 26-15/16” (68.4 cm)
66”W. 32-15/16” (83.7 cm)
36”W. 35-7/8” (91.1 cm)
42“W. 41-7/8” (106.4 cm)
54”W. 53-7/8” (136.8 cm)
66”W. 65-7/8” (167.3 cm)
B
900 or 1200 CFM Exterior or In-Line Ventilator Installation
for all Island Hoods
Top View
Top View
Top View
Top View
900, 1200 or 1500 CFM Exterior or In-Line Ventilator Installation
for all Island Hoods
1200 CFM Interior Ventilator Installation
for all Island Hoods
(VIH Island Hoods
)
(VIH Island Hoods)
