Viking 24" - WH 18 H. Wall Hoods

9
Dimensions & Specifications
8
B
A
1
8”
(4
5
.7 c
m)
12
”
(
3
0
.
5
c
m)
6”
(
15
.2
cm)
A (Hood width)
24”W. 23-7/8“ (60.6 cm)
30”W. 29-7/8“ (76.2 cm)
36”W. 35-7/8” (91.1 cm)
42”W. 41-7/8” (106.4 cm)
48“W. 47-7/8” (121.6 cm)
54”W. 53-7/8” (136.8 cm)
60”W. 59-7/8” (152.1 cm)
66”W. 65-7/8” (167.3 cm)
B (Hood depth)
24”D. 24” (61.0 cm)
27”D. 27” (68.6 cm)
(VWH 18”H. 24” Deep Wall Hoods 24”, 30”, 36”, 42”, 48”, 54”, 60”, & 66”)
(VWH 18”H. 27” Deep Wall Hoods 30”, 36”, 42”, 48”, 54”, 60”, & 66”)
* A 1,200 CFM interior- or exterior-power ventilator should be used when installed over range/rangetop with gas char-grill.
Max duct run is 50 ft.
** It is recommended that the 1,500 CFM ventilator be used with longer duct runs. Max duct run is 75 ft.
NOTE: Maximum amp rating for hoods includes recommended ventilator kit rating; All products must be hard wired with 2-
wire with ground. An interior- or exterior-power ventilator kit must be purchased for installation with all 18”H. hoods.
3
0
”
m
i
n
.
(
7
6
.
2
c
m
)
t
o
3
6
”
m
a
x
.
(
9
1
.
4
c
m
)
6
6
”
m
i
n
.
(
1
6
7
.
6
c
m
)
t
o
7
2
”
m
ax
.
(
1
8
2
.
9
c
m
)
3
6
”
(
9
1
.
4
c
m
)
Clearance Dimensions
(VWH 18”H. Wall Hoods)
NOTE: Optional duct cover sold separately.
VWH 18”H. Wall Hoods
Description 24” 30” 36” 42” 48” 54” 60” 66”
Duct cover width
23-7/8”
(60.6 cm)
29-7/8”
(75.9 cm)
35-7/8”
(91.1 cm)
41-7/8”
(106.4 cm)
47-7/8”
(121.6 cm)
53-7/8”
(136.8 cm)
59-7/8”
(152.1 cm)
65-7/8”
(167.3 cm)
Duct cover depth
12” (30.5 cm)
Duct cover height
12” (30.5 cm)
Number of lights
2 2 2 2 3 3 4 4
Number of filters
2 2 2 2 3 3 4 4
Heat lamps
1 1 1 1 2 2 2 2
Interior ventilator kits
VINV300/
600
VINV300/
600/1200
VINV300/
600/1200
VINV600/
1200
VINV1200* VINV1200* VINV1200* VINV1200*
Exterior ventilator kits
DEV900/
1200*
DEV900/
1200*
DEV900/
1200*
DEV900/
1200*
DEV1200*/
1500**
DEV1200*/
1500**
DEV1200*/
1500**
DEV1200*/
1500**
In-line ventilator kits
DIL900/1200 DIL900/1200 DIL900/1200 DIL900/1200 DIL1200 DIL1200 DIL1200 DIL1200
Interior duct size
7”
(17.8 cm)
7”/10”
(17.8/25.4 cm)
7”/10”
(17.8/25.4 cm)
7”/10”
(17.8/25.4 cm)
10”
(25.4 cm)
10”
(25.4 cm)
10”
(25.4 cm)
10”
(25.4 cm)
Exterior duct size
10” (25.4 cm)
Interior—Maximum amps
4.9/5.9 4.9/5.9 4.9/5.9 11.5 11.5 11.5 11.5 11.5
Exterior—Maximum amps
8.7/6.0 8.7/6.0 8.7/6.0 8.7/6.0 8.5/9.2 8.5/9.2 8.9/9.2 8.9/9.2
In-Line—Maximum amps
6.0/7.9 6.0/7.9 6.0/7.9 6.0/7.9 10.3 10.3 10.7 10.7
