Viking 24" - Clearance Dimensions; Interior Ventilator Dimensions

6
Clearance Dimensions
7
* NOTE: When installing with a 24” high-shelf,
the 27” (68.6 cm) max. dimensions must be used.
2
4”
mi
n.
(6
1.
0
c
m)
t
o
2
7”
ma
x
.
*
(6
8.
6
c
m)
60”m
in.
(1
5
2.4
cm
)
t
o
63”m
ax.
(1
6
0
.0
cm
)
36
”
(
91
.
4
c
m)
Interior Ventilator Dimensions
A
B
C
D
18”
(4.6 cm)
3-7/8”
(9.8 cm)
3-4”
(1.9 cm)
7” (17.8 cm) dia.
duct location
Electrical
hookup
1/2”
(1.3 cm)
4”
(10.2 cm)
3-1/2”
(8.9 cm)
A
24”W. 23-7/8” (60.6 cm)
30”W. 29-7/8” (75.9 cm)
36”W. 35-7/8” (91.1 cm)
B
24”W. 5-1/4” (13.3 cm)
30”W. 8-1/4” (20.9 cm)
36”W. 11-1/4” (28.6 cm)
C
24”W. 11-15/16” (30.3 cm)
30”W. 14-15/16” (37.9 cm)
36”W. 17-15/16” (45.6 cm)
D
24”W. 5/8” (1.6 cm)
30”W. 3-5/8” (9.2 cm)
36”W. 6-5/8” (16.8 cm)
460 CFM Interior Ventilator Installation
Top View
(VWH 10”H. Wall Hoods w/Standard Ventilator)
(VWH 10”H. Wall Hoods w/Standard Ventilator)
