Viking 24" - Installation (VWH 18 H. Wall & VCWH Chimney Wall Hoods); Duct Cover Option (VWH 18 H. Wall Hoods)

4342
1
-
1
3
/
1
6
”
(
4
.
6
c
m
)
1
-1/2”x 3/4”
(3.8 cm) x (1.9 cm)
wood strip
1
5
/16”
nut driver
Slot for
w
ood strip
2
5/16”
nut driver
Measure down 1-13/16 (4.6 cm) from desired height of
hood and secure 1-1/2” x 3/4” wood strip (provided
locally) to wall using screws provided.
Use additional mounting screws to secure hood to
wood strip.
Installation (VWH 18”H. Wall & VCWH Chimney Wall Hoods)
3
5/16”
nut driver
5/1
6”
nut
dri
v
er
CAUTION: Secure vent hood to wall using screws
provided. Use additional mounting screws and wall
anchors, if necessary.
CAUTION: If not using a duct cover, using screws
provided, make sure top mounting screws are secured
into soffit or cabinet framing use additional mounting
screws, if necessary.
To install ventillation kit
refer to ventillation kit
installation instructions.
1
2
3
4
Slide filter front over front lip. Push filter rear up, then
slide back over rear lip.
1
2
3
5
Slide spacer front over front lip. Push spacer rear up,
then slide back over rear lip.
1
2
3
6
Slide filter front over front lip. Push filter rear up, then
slide back over rear lip.
1
2
2
Measure distance from ceiling to canopy.
Slide the duct cover in place and fasten from inside
canopy using the sheet metal screws provided.
Duct Cover Option (VWH 18”H. Wall Hoods)
