Built-In Island Custom Ventilator
System Dimensions
(VICV Models)
28-7/16” (72.2 cm)
27-7/16” (69.7 cm)
(including screw heads)
1-1/2”
(3.8 cm)
1”
(2.5 cm)
5/8”
(1.6 cm)
11-1/2”
(29.2 cm)
28-7/16” (72.2 cm)
27-7/16” (69.7 cm)
(including screw heads)
1-1/2”
(3.8 cm)
5/8”
(1.6 cm)
11-1/2”
(29.2 cm)
6”
(15.2 cm)
17-1/4”
(43.8 cm)
11/16”
(1.7 cm)
External Power
Internal Power
B
5-3/4”
(14.6 cm)
5/8” (1.6 cm)
A
10” (25.4 cm)
dia. duct location
900 or 1200 CFM External or In-Line Power
36”, 42” W. Models
7” (17.8 cm)
dia. duct location
B
A
5/8” (1.6 cm)
5-3/16”
(13.2 cm)
600 CFM Internal Power
36”, 42” W. Models
A
36” W. 34-1/4” (87.0 cm)
42” W. 40-1/4” (102.2 cm)
B
36” W. 17-1/8” (43.5 cm)
42” W. 20-1/8” (51.1 cm)
Built-In Island Custom Ventilator
System Dimensions
(VICV Models)
B
5-3/4”
(14.6 cm)
5/8” (1.6 cm)
A
10” (25.4 cm)
dia. duct location
900, 1200 or 1500 External or In-Line Power
42”, 54”, 66” W. Models
1200 CFM Internal Power
42”, 54”, 66” W. Models
5/8” (1.6 cm)
A
10” (25.4 cm)
dia. duct location
5-1/2”
(14.0 cm)
B
A
54” W. 52-1/4” (132.7 cm)
66” W. 64-1/4” (163.2 cm)
B
54” W. 26-1/8” (66.4 cm)
66” W. 32-1/8” (81.6 cm)
