Viking DFBB363 - Cabinet Information; Top View

43
Top View
Flush mount cabinet doors
24”
(
61
.
0
c
m
)
st
and
ard
ca
bi
n
e
t
de
p
t
h
24-3/4”
(62.9 cm)
Wall
3/4”
(1.9 cm)
full end panel
Flush
Cabinet
door
Door
3/4”
(1.9 cm)
overlay
panel
1/4”
(0.6 cm)
base
panel
Cabinet Information
44
Top View
Top View
Door
24”
(61.0 cm)
standard
cabinet
depth
25”
(63.5 cm)
countertop
depth
Wall
3/4”
(1.9 cm)
full end panel
Door
Wall
1/4”
(.63 cm)
if standard 25” (63.5 cm)
standard cabinet
depth is used
3/4”
(1.9 cm)
full end panel
25”
(63.5 cm)
Flush
1/4”
(.63 cm)
if standard 25” (63.5 cm)
standard cabinet
depth is used
Flush
3/4”
(1.9 cm)
overlay
panel
1/4”
(0.6 cm)
base
panel
3/4”
(1.9 cm)
overlay
panel
1/4”
(0.6 cm)
base
panel
Cabinet Information
Full overlay models, (with 3/4” [1.9 cm], thick panels and custom handles locally supplied), fit flush in 25”
(63.5 cm) deep (countertop depth) cabinet openings with no protrusion into room except custom handles
Full overlay models can be installed in standard 24” (61.0 cm) deep openings. However, the door faces
and top ventilation grille will protrude 3/4” (1.9 cm) into the room. This is ideal for alignment with full
overlay cabinet doors.
