Disassembly
©2012 Viking Preferred Service 13
WARNING!
Parts Location–Control Panel
To avoid risk of electrical shock, personal injury, or death, disconnect electrical power source to unit, unless
test procedures require power to be connected. Ensure all ground wires are connected before certifying unit as
repaired and/or operational.
Low Voltage Board
Inverter
Power Disconnect SwitchHigh Voltage Board
Overlay Switch
Upper Grill Assembly
Control Panel
