Disassembly
22 ©2012 Viking Preferred Service
WARNING!
To avoid risk of electrical shock, personal injury, or death, disconnect electrical power source to unit, unless
test procedures require power to be connected. Ensure all ground wires are connected before certifying unit as
repaired and/or operational.
Water Valve Drain pan heater
Service fan
Icemaker Freezer thermistor Evaporator fan
Parts Location – Freezer Compartment
