Disassembly
12 ©2012 Viking Preferred Service
WARNING!
Parts Location–Control Panel
To avoid risk of electrical shock, personal injury, or death, disconnect electrical power source to unit, unless
test procedures require power to be connected. Ensure all ground wires are connected before certifying unit as
repaired and/or operational.
Low Voltage Board
Inverter
Power Disconnect SwitchHigh Voltage Board
Overlay Switch
Upper Grille Assembly
Control Panel
To Next Page
