28
17
Make sure evaporator pan is in correct location.
15
Wall
2 x 4
Refrigerator
Screw
16
Lift unit o rollers to desired height and level unit using a
5/16” head wrench. NOTE: DO NOT use an electric device.
Overtightening can cause damage.
Insert mounting screws into 2x4 attached to wall stud
1
2
18
2
1
3
19
Align holes on both ends of louvered panels
and insert screws.
Using a Phillips screwdriver, attach the
kickplate to the unit and adjust to desired height.
Kickplate Installation
Installation
