Minimum clearances from adjacent combustible construction:
Below cooking surface (36” [91.4 cm] and below)
• Sides - 0”
• Top grate support - 36” (91.4 cm)
Above cooking surface (above 36” [91.4 cm])
• Sides - 12” (30.5 cm)
• Within 12” (30.5 cm) side clearance, wall cabinets no deeper than 13” (33.0 cm) must be minimum 18” (45.7 cm)
above cooking surface
• Wall cabinets directly above product must be a minimum of 58” (147.3 cm) above cooking surface, unless a range hood is
installed above the cooking surface.
• Rear - 3/8” (0.9 cm) with 10” backguard or high shelf; 0” with island trim and non-combustible rear wall;
• 6” (15.2 cm) with island trim and combustible rear wall
Dual Fuel 36” and 48” W. Ranges
Description
36” W. Models 48” W. Models
Overall width 35-7/8” (91.1 cm) 47-7/8” (121.6 cm)
Overall height To top of side trim – 35-15/16” (91.3 cm) min. 37-9/16” (95.4 cm) max.
Legs adjust – 1-5/8” (4.1 cm)
Overall depth from
rear*
To end of side panel – 25-1/4” (64.1 cm)
To front of door – 26-15/16” (68.4 cm)
To end of door handle – 30” (76.2 cm)
*Add 3/8” (1 cm) to overall depth for models installed against a combustible wall.
Additions to Base
Height
To top of island trim – add 1” (2.5 cm)
To top of backguard – add 10” (25.4 cm)
To top of high shelf – add 24-1/8” (6.3 cm)
Gas requirements Shipped Natural or LP/Propane, accepts standard residential 1/2” (1.3 cm) ID gas service line.
Unit is field convertible with proper conversion kit.
Gas manifold
pressure
Natural 5.0” W.C.P./ Liquid Propane L/P 10.0” W.C.P.
Electrical
requirements
See Electrical Requirements information
Maximum amp usage 240V - 28.5 amps / 208V - 24.7 amps 240V - 43.0 amps / 208V - 37.3 amps
Surface burner rating
Natural gas/LP
Front: (3) 23,000 BTU (6.7 kW) / 21,500 BTU (6.3 kW)
Rear: (2) 15,000 BTU (4.4 kW) / 13,500 BTU (4.0 kW)
(1) 8,000 BTU (2.3 kW) / 8,000 BTU (2.3 kW)
Front: (4) 23,000 BTU (6.7 kW) / 21,500 BTU (6.3 kW)
Rear: (3) 15,000 BTU (4.4 kW) / 13,500 BTU (4.0 kW)
(1) 8,000 BTU (2.3 kW) / 8,000 BTU (2.3 kW)
Griddle burner rating
15,000 BTU (4.4 kW) / 13,500 BTU (4.0 kW)
Oven interior width 30-5/16” (77.0 cm) Right oven - 25-5/6” (65.6 cm)
Left oven - 13-3/4” (34.9 cm)
Oven interior height
16-1/2” (41.9 cm)
Oven interior depth
Overall
AHAM
19-1/2” (49.5 cm)
16-13/16” (42.7 cm)
Oven volume
Overall
AHAM
5.6 cu. ft.
4.9 cu. ft.
Right - 4.7 cu. ft. / Left - 2.6 cu. ft.
Right - 4.1 cu. ft. / Left - 2.2 cu. ft.
Approximate
shipping weight
525 lbs. (236.6 kg) 692 lbs. (288.5 kg)
Note: Clearances from non-combustible materials are not part of the ANSI Z21.1 scope and not certified by CSA.
Clearances to non-combustible materials must be approved by the authority having jurisdiction.
