30 - ENGLISH
5.3.12
Remove the smart card.
The LED blinks green, waiting for a syn-
chronising smart card.
Synchronising
card
Synchronising
card
5.3.13
Insert a smart card programmed by the
synchronising reader.
5.3.14
The LED switches off to signal that the
smart card code has been copied, and
the reader synchronised.
5.3.9
Insert into the reader a smart card pro-
grammed by that same reader, to enable
continuation of the procedure.
Card
already
programmed
Card
already
programmed
5.3.10
If the smart card is not recognised, the
LED will blink red.
Remove the incorrect smart card and
insert the correct one.
5.3.11
If the smart card is recognised, the LED
switches off.
