Manual programming
Basic interphone/monitor programming is as follows:
- Programming ID, which must be performed on the interphone that re
-
ceives the call individually or on the first interphone of a group of inter-
phones/monitors with simultaneous calls (master interphone).
- Programming secondary ID, which must be done for interphones associ-
ated with a master interphone/monitor.
- Programming programmable buttons or changing the default setting of
supplementary buttons, for auxiliary services or intercommunicating calls.
Programming must be carried out with the system switched on, without active
communication and only after the interphones/monitors have been connected
to the system and the entrance panels have been programmed.
N.B.: all the programming or deletion phases must be performed with
the interphone/monitor handset lifted and held against the user’s ear.
Programming ID identification code
The identification code is programmed by means of a main entrance panel
(MASTER), already configured and present in the system.
The interphone is supplied without associated identification code. To verify
this, press the lock release button and the interphone should emit an audible
signal (triple beep).
To program the ID, proceed as follows:
1) Lift the handset.
2) Press buttons B and A simultaneously and hold them down until LED F
(ringtone mute) begins flashing.
3) Release the buttons.
4) Press button C and hold it down (for 2 sec.) until the handset emits an au-
dible signal and communication between the interphone and the outdoor
entrance panel begins.
5) Release button C.
Important: you will have 5 s in which to press button C (as indicated in step
4). If button C is not pressed within the 5 s, steps 1, 2 and 3 must be repeated.
6) You now have approx 30 seconds to assign the ID code of the external
entrance panel:
- in the case of an alphanumeric panel, key in the primary ID and press
the “bell” button to confirm.
- in the case of a push-button entrance panel, press the button you want
to use to call the interphone.
Important: If the system already contains an interphone with the same as
-
sociated identification code, the entrance panel emits a low tone and the
process must be repeated from the start in order to assign a different code.
Programming secondary ID
Programming the secondary ID is only necessary when you want more than
one interphone/monitor to ring in response to the same pushbutton or call
code. The interphones/monitors that are to ring at the same time are associ-
ated with the same group. The “master” interphone/monitor is programmed
first by means of the “identification code programming” procedure described
above, while the additional group interphones/monitors are programmed with
the secondary identification code.
The maximum number of monitors that can be associated with the same
group without using SaveProg software is 3 plus a master unit. Alternatively,
a SaveProg software can be used to program activation of the ringtone of all
video door entry units and the monitor of only the master unit. Before answer-
ing from a secondary video door entry unit, the relevant monitor can be turned
on by means of the self-start button.
To program the secondary ID, proceed as follows:
1) Lift the handset.
2) Press buttons B and A simultaneously and hold them down until LED F
(ringtone mute) begins flashing.
3) Release the buttons.
4) Press buttons A and C simultaneously and hold them down (for 2 sec.)
until the handset emits an audible signal and communication between the
interphone and the outdoor entrance panel begins.
5) Release buttons A and C.
Important: you will have 5 s in which to press buttons A and C (as indicated
in step 4). If buttons A and C are not pressed within the 5 s, steps 1, 2 and
3 must be repeated.
6) You now have approx 30 seconds to assign the ID code of the external
entrance panel:
- in the case of an alphanumeric panel, key in the primary ID and press
the “bell” button to confirm.
- in the case of a push-button entrance panel, press the button you want
to use to call the interphone.
Important: When programming the primary and secondary ID, the inter
-
phones undergoing programming automatically acquire a code that depends
on the association with the button or code used to call the outdoor entrance
panel. Correspondence between the primary ID and the respective secondary
ID codes is provided in the table below.
Example: If ID = 8 is given to a second interphone, the automatic second
interphone identification attribution procedure will automatically assume ID
= 72 (see table).
When a call is made to ID = 8, both interphones will chime and both can be
used to answer. If, on the other hand, in the case of an alphanumeric panel
you enter 72 (the ID automatically assigned by the procedure), a chime is
emitted by the interphone for which the secondary ID assignation procedure
was carried out and only this interphone can be used to answer the call.
Table of primary and corresponding secondary ID codes:
Primary ID
Secondary ID
1 2 3
1 51 52 53
2 54 55 56
3 57 58 59
4 60 61 62
5 63 64 65
6 66 67 68
7 69 70 71
8 72 73 74
9 75 76 77
10 78 79 80
11 81 82 83
12 84 85 86
13 87 88 89
14 90 91 92
15 93 94 95
16 96 97 98
17 99 100 101
18 102 103 104
19 105 106 107
20 108 109 110
21 111 112 113
22 114 115 116
23 117 118 119
24 120 121 122
25 123 124 125
Primary ID
Secondary ID
1 2 3
26 126 127 128
27 129 130 131
28 132 133 134
29 135 136 137
30 138 139 140
31 141 142 143
32 144 145 146
33 147 148 149
34 150 151 152
35 153 154 155
36 156 157 158
37 159 160 161
38 162 163 164
39 165 166 167
40 168 169 170
41 171 172 173
42 174 175 176
43 177 178 179
44 180 181 182
45 183 184 185
46 186 187 188
47 189 190 191
48 192 193 194
49 195 196 197
50 198 199 200
Important: to delete from a group, the programming deletion procedure de-
scribed in the “Default data restore procedure” section must be performed.
Button programming
Important: without SaveProg software, the only functions that can be as-
signed are intercommunication, specific entrance panel self-activation,
restoring buttons programmed by the installer to their default settings and
restoring default data.
Button programming procedure for intercommunicating calls
To program the buttons, proceed as follows:
1) Press the “talk/listen” button or lift the handset (depending on model in-
stalled) for the interphone/monitor TO BE CALLED.
2) Lift the handset to be programmed (the caller handset).
3) Press buttons B and A on the interphone to be programmed (caller) simul-
taneously and hold them down until LED F (ringtone mute) begins flashing.
4) Release buttons B and A.
5) Press and hold down the button to be programmed (e.g. E1, E2, E3, E4).
6) Wait until the interphone handset emits a continuous tone.
7) Release the button to be programmed on the caller interphone.
8) Press a button (lock/F1/F2) on the interphone/monitor to be called.
9) An audible signal in the handset of the (caller) interphone being pro-
