Vimar ELVOX K40980 User Manual

14
K40980 - K40981
EN
Power Supply Unit Installation
ThepowersupplyunitisinstalledbysecuringittoaDINrail,andiscompatiblewithVimarcontrolunits.
AredLEDindicateswhenthedeviceisoperatingcorrectly;whentheLEDison,itisworkingnormally.
-
+
INPUT (L/N):~100-240V
50/60Hz 2.5A
OUTPUT (+/-):32V
N
40105
(OS)
-
+
2.5A CONT+1A INT
INT: 90s ON/180s OFF
L
-
+
INPUT (L/N):~100-240V
50/60Hz 2.5A
OUTPUT (+/-):32V
N
40105
(OS)
-
+
2.5A CONT+1A INT
INT: 90s ON/180s OFF
L
-
+
INPUT (L/N):~100-240V
50/60Hz 2.5A
OUTPUT (+/-):32V
N
40105
(OS)
-
+
2.5A CONT+1A INT
INT: 90s ON/180s OFF
L
Thepowersupplyunitlabelshowsthat:
1) Atthetopofthedevicethereisaninputportwithterminalsprotectedbyaplasticterminalcover,forthemainspower
connection.
 Theneutralterminalisidentiedwiththeletter(N);thelineterminalisidentiedwiththeletter(L).
2) Atthebottomofthedevicethereisaportforconnectingthe2-wireBUSforIM(IndoorMonitororindoorstation)andaport
forconnectingthe2-wireBUSforOS(OutdoorStation).
 Eachporthasa“+”terminalanda“-”terminal.Werecommendconnectingcablesofthesamecolourtothe“+”and“-”
terminals.
Connectthe2-wireBUScablesfromthe+and-terminalsoftheIMportonthepowersupplyunittothecorrespondingterminalsof
theBUS_INportontheindoormonitor.
Connectthe2-wireBUScablesfromthe+and-terminalsoftheOSportonthepowersupplyunittotheBUS+andBUS-terminals
ofthe2-wireBUSportontheoutdoorstation.
