165 cm
120 cm
Outdoor Station Installation
The outdoor stationcanbeinstalledexternallyonawallsurfacewithorwithouttherainguardprovided.
Wheninstallingthedevice,takecaretoopenthefrontcasebylooseningthexingscrewontheundersideofthefrontcoverplate,
usingthesecuritykeyprovided.
Fastenthebaseoftheoutdoorstation,withorwithoutrainguard,tothewallwiththe4screwsand4wallplugsprovided.
Werecommendfasteningthedeviceassetoutbelow.
Inordertooperate,theoutdoorstationmustbeconnectedtothesystembus.Theconnectioncanbemadebyconnectingthebus
to the BUS+ and BUS- connectors.
