OutdoorStationCongurationandConnection
Inorderfortheoutdoorstationtooperate,makesureyouconnectthebustotheBUS+ and BUS-(non-polarised)terminals.
Tocompletetheinstallation,notethatthefollowingcanbeconnected:
- The GND and LOCKterminalstocontrolanelectriclock12VDC,1.1Apeakcurrent,200mAmaintenancecurrent;
- The COM and NO/NCterminalstocontrolanactuatorusingarelaywithNOorNCcontact,max30VDC,6A;
 Therelaymodeisdenedbythepositionofthejumperontheside:
 -JumperplacedbetweentheupperpairofPINs:NO(normallyopen)mode
 -JumperplacedbetweenthelowerpairofPINs:NC(normallyclosed)mode
- The GND and EXITterminalstoconnectoneormoredoorreleasebuttons(NOvoltage-freecontact).
Congurationdip
switch
(defaultsettingfor
one-familymaster
outdoorstation)
Reset
(Reserved)
Adjustment-
Volume
(Potentiometer)
(prog)
Exit
button
Power
lock
2-wire
Bus
Relay
NC/NO
relay
NO/NCCOMBUS-BUS+
LOCKGNDEXITGND
Reset
Iflongpressed,itrestoresthedevicetoitsdefaultfactorysettings,includingtheRFIDreader;ifpressedtwiceinrapidsuccession,
itactivatestheRFIDrecongurationandresetprocedure.
Volume adjustment (potentiometer)
Tocompletethedescriptionofthefunctionsthatcanbesetduringinstallation,notethattheaudiovolumecanbeadjustedwiththe
potentiometer.
