Notethat:
- Forone-familyoutdoorstations,thecallbuttoncorrespondstoapartment1.
- Fortwo-familyoutdoorstations,thelowercallbuttoncorrespondstoapartment1,whereastheuppercallbuttoncorresponds
toapartment2.
- Forfour-familysystems,thepushbuttonmappingisaccordingtothefollowingscheme:
VIMAR
ROSSI
BIANCHI
VIMAR
VIMAR
ROSSI
BIANCHI
VIMAR
2
1
3
1
4
2
1
Forthecongurationofthenumberofeachapartment,pleaserefertotheparagraphentitled“IndoorStation
Conguration".
Reset push button:
Theresetpushbuttonperformsafactoryresetoftheoutdoorstation,i.e.itreturnstheoutdoorstationbacktoitsoriginalfactory
setting.
Thefactoryresetoftheoutdoorstationisperformedbylongpressingtheresetpushbutton(approx.5s).Theactivationofthe
resetisconrmedbyabeep.
Note:ifitisnecessarytoperformafactoryresetontheentirevideodoorentrysystem,werecommendthefollowingprocedure:
1) PerformaFactoryResetoftheslaveindoorstation
2) PerformaFactoryResetofthemasterindoorstations
3) Updatethedipswitchcongurationrelatingtotheoutdoorstations,ifnecessary
4) PerformanorderedFactoryResetoftheoutdoorstations,fromtheoutdoorstationwithID“1”onwards.
5) Wait1minute
TheoutdoorstationisalsoequippedwithanNFCtagreaderforMifarekeysart.40169,01598and01817.
To use NFCkeys,conguretheRFIDreaderaftertheoutdoorstationhasbeenconnectedandpowered.
CongurationofNFCkeysisspecicandshouldbecarriedoutforeachoutdoorstation.
