vimec S10 - Flap Parts List; Flap Component Codes and Descriptions

51
RIF CODICE QTA' DESCRIZIONE
1 1 2 2 3 3 3 4 5 6 7 8 9
2594086 2594087 2304276 2304277
28941299 28941388 28941389
4404004 2904197 3704024 1304413 0904001 2504010
1 1 1 1 2 2 2 4 1 1 1 1 1
LAMIERA LAMIERA LAMIERA INFERIORE LAMIERA INFERIORE PROFILO IN GOMMA PROFILO IN GOMMA PROFILO IN GOMMA CERNIERA LEVA BANDELLA RULLO PERNO DISTANZIALE CAMMA
DESCRIPTION
SHEET METAL PLATE SHEET METAL PLATE LOWER SHEET METAL PLATE LOWER SHEET METAL PLATE RUBBER PROFILE RUBBER PROFILE RUBBER PROFILE HINGE FLAP LEVER ROLL PIN SPACER CAM
7512001
FLAP
