5. TECHNICAL DATA
- Lifting system
Worm screw plus motor and inverter
- Operating data
Travel direction Up/Down
Speed 0.05 m/s
Payload See nameplate on unit
- Duty cycles
Normal duty 20 Cycles/day
- Ambient conditions from -5° to +60° C. Humidity 90% max. (use in
Temperature bathrooms and swimming-pools is not permit¬ted).
- Electrical system
Motor 1.1 kW
Voltage 220 V (50 Hz) Single-phase
Auxiliary circuit at 24 VDC
IP protection degree IP 54
- Controls Hold-to-run type; on the lift: protected up and down
buttons, illuminated call buttons at fl oors. All buttons
are of hold-to-run type; the controls at the fl oors are
enabled by means of removable keys.
