7. Installation
DC22 can be mounted on the left side of handlebar close to its grip. Adjust the
angle for a good screen view. Cut off the power before connecting the corresponding
connectors between display and controller.
8. General Operation
Switching the E-bike System mode ON/OFF
To switch on the E-bike system and provide the power supply to the controller, hold the
MODE button for 1s.
To switch off E-bike system, hold the MODE button for 1s. The E-bike system no
longer uses the battery power.
When E-bike system is switched off, the leakage current is less than 1 μA.
When the E-bike is parked for over 15 minutes, the E-bike system switches
off automatically.
Display Interface
After switching on the E-bike system, the display will show Current Speed and
Trip Distance, ODO, Power and battery SOC by default.
Press the “ON/OFF” button and switch between:
TRIP →Max. Speed (Km/h) →Avg. Speed (Km/h) → ODO(km)→Trip Time
(Min.) →POWER(W)
