10
(1) Wedge adaptor
(2) Wedge adaptor operating lever
(3) Wedge adaptor securing screw
(4) Pan brake lever
(5) Tilt brake lever
(6) Carrying handle
(7) Level bubble illumination switch
(8) Level bubble
(9) Pan drag adjustment knob
(10) Pan bar clamp
(11) Tilt drag adjustment knob
(12) Slide plate clamp
(13) Slide plate adjustment knob
Fig 1 Vector 750 Pan & Tilt Head (Left-hand Side)
(1)
(8)
(2)
(4)
(3)
(5)
(6)
(7)
(9)
(10)
(11)
(12)
(13)
