(14) Sliding plate clamp lever
(15) Pan bar mounting
(16) Tilt drag adjustment knob
(17) Pan drag adjustment knob
(18) Battery cover
(19) Mitchell adapter key way
(20) Four-hole mounting plate
Fig 2 Vector 90 Pan and Tilt Head (Left-Hand Side)
(14)
(15)
(16)
(17)
(18)
(19)
(20)
