9
(1) Wedge adapter operating lever
(2) Sliding plate adjustment handle
(3) Carrying handle
(4) Centre lock plunger
(5) Balance knob
(6) Tilt brake lever
(7) Pan brake lever
(8) Centre lock release lever
(9) Illuminated level bubble
(10) Illumination button
(11) Graduated sliding plate
(12) Wedge adapter
(13) Wedge adapter mounting screw
Fig 1 Vector 90 Pan and Tilt Head (Right-Hand Side)
(8)
(1)
(2)
(3)
(4)
(7) (6)
(5)
(9)
(10)
(12)
(13)
(11)
