Color shortage (red, green, or blue)
• Ensure that the pins in the interface are curved.
Image position is not centered/the size is not right
• Please adjust Clock or Auto setting.
Color difference (colors are not optimized)
• Adjust RGB color or reset color temperature.
Section 12: Specifications
Item Detail
Model Number NB24CW/NB24CB
Screen Size 23.6’’
Curvature 1800R
Viewing Angle 178° (H)/178° (V)
Aspect Ratio 16:9
Resolution 1920x1080p
Backlight E-LED
LED Indicator Power on: Blue (LED); Power saving : Blue Flicker
(LED)
Typical Brightness 220 cd/m
2
Default Color Temp. 6500
Color Gamut 92% sRGB; 68% NTSC
Contrast Ratio 3,000:1 (Static)
Dot Pitch 0.0905 x 0.2715mm
Response Time GTG 8MS
Refresh Rate 60-75 Hz (75Hz Max.)
Speaker 4Ω/3W x 2
Ports VGA x 1, HDMI x 1
Power Adapter OUTPUT: DC 12V / 3A
INPUT: AC100-240V ~ 50/60Hz 1.0A
Power Consumption Typical: 25W, Max:33W; Standby ≤ 0.5W
OSD Language
English, 简体中文，Nederlands, Français, Deutsch,
한국어，Español, Русский, Português, Türkçe, Italiano,
Polski
Usage Temp. 32°F~95°F (Operating), -4°F~140°F (Storage), 10-90%
RH (Non-Condensing)
Tilt Angle Forward -5°; Backward 15°
VESA Compatibility 75X75 mm
Dimension (With Stand) 21.3 x 15.93 x 7.13 in (540.6 x 404.7 x 181mm)
Weight 6.94 lbs(Net) / 10.47 lbs(Gross)
