Section 4: Stand Installation
Keep the foam underneath the monitor before attaching the stand.
1. Open the package, take out the product with foam still attached, and gently place
it on a desktop or table.
2. Take out the two parts of the stand, and remove the foam covering the back of the
monitor. Next, insert the stand stem into the opening on the back of monitor, then
use the NO. 1 screws to fasten it to the monitor.
Stand Stem
NO.1 Screws
6mm x 2
3. Use the NO.2 screws to fasten the base to the stem.
NO.2 Screws
8mm x 2
Base
4. Make sure the stand is securely attached to the back of the monitor then remove
the monitor from the remaining foam and stand it up on a table or desk.
