16
• Check that the graphics card is installed properly.
• Check that the signal line connects securely with the monitor.
• Check that the pins in the interface are not curved.
Color shortage (red, green, or blue)
• Check cable connectors for curved or damaged pins. Replace cables if needed.
Image position is not centered/the size is not right
• Please adjust Clock or Auto setting.
Color difference (colors are not optimized)
• Adjust RGB color or reset color temperature.
Section 11: Specifications
Item Detail
Model Number NFI24DBA
Screen Size 23.8’’
Display Type IPS
Viewing Angle 178°(H) / 178°(V)
Aspect Ratio 16:9
Resolution 2560 x 1440p
Backlight E-LED
LED Indicator Power on: Blue (solid); Power saving: Blue (ashing)
Typical Brightness 300 cd/m² (max.)
Default Color Temp. 6500
Color Gamut 119%~123% sRGB; 85%~88% NTSC
Contrast Ratio 1000:1 (static)
Pixel pitch 0.2058 x 0.2058 mm
Response Time 5ms (GTG)
Refresh Rate 75Hz (max.)
Adaptive Sync Range
48-75Hz
Ports 1x DP, 1x HDMI 2.0, 1x Type-C, 2x USB 2.0, 1x USB
2.0 Type-B, 1x 3.5mm audio out
Power DC 12V/4A
Power Consumption Max: 48W; Standby <=0.5W
OSD Language
English,简体中文,한국어, Español, Русский, 日本語,
Français
Usage Temp. 32°F~95°F (operating), -4°F~140°F (storage), 10-90%
RH (non-condensing)
Tilt Angle Forward 5°; Backward 15°
VESA Mounting 100mm x 100mm
Dimension (With Stand) 21.29 x 16.4 x 7.48 in (540.64 x 416.53 x 190 mm)
Weight 8.82 Ib. / 12.12 Ib. (incl. packaging)
