8
3. Remove the foam covering the back of the monitor. Locate the two top slots of the
opening on the back of monitor. Insert the mounting plate into the two top slots.
Continue to press in until it clicks into place to make sure the stand is installed in
place.
Mounting Plate
4. Place the monitor on your desktop or table after completing the installation and
carefully adjust monitor’s height, angle and/or orientation as desired.
Orientation adjust 90°
Pivot adjust 20°
Tilt adjust +5° / -15°
Height adjust 5.12 in. (130 mm)
5. With the stand fully assembled, remove the remaining foam on monitor and stand
it up on a at, level desktop or table. Press the button to remove the monitor from
the bracket if mounting.
Button
Make sure the monitor is laid on a at surface before removing the stand.
