Chapter 4 Analog Input Manual VIPA System SLIO
4-28 HB300E - SM - Rev. 09/38
The parameter data may be accessed during runtime with the following
record sets:
Record set
Nr. Byte
Meaning Default
0 0 Diagnostics
Bit 5 ... 0: reserved
Bit 6: Diagnostics interrupt (1: activated)
Bit 7: Process interrupt (1: activated)
1 Bit 0: Wire break recognition channel 0 (1: on)
Bit 1: Wire break recognition channel 1 (1: on)
Bit 2: Wire break recognition channel 2 (1: on)
Bit 3: Wire break recognition channel 3 (1: on)
Bit 7 ... 4: reserved
2 Bit 0: Limit value monitoring channel 0 (1: on)
Bit 1: Limit value monitoring channel 1 (1: on)
Bit 2: Limit value monitoring channel 2 (1: on)
Bit 3: Limit value monitoring channel 3 (1: on)
Bit 7 ... 4: reserved
3 reserved
1 0 Bit 0, 1: Temperature system
00: °C
01: °F
10: K
Bit 7 ... 2: reserved
1 Bit 0, 1: Interference frequency suppression
01: 60Hz
10: 50Hz
Bit 7 ... 2: reserved
128 0 Function number channel 0 50h
1 Function option channel 0 00h
2, 3 Upper limit value channel 0 7FFFh
4, 5 Lower limit value channel 0 8000h
129 0 Function number channel 1 50h
1 Function option channel 1 00h
2, 3 Upper limit value channel 1 7FFFh
4, 5 Lower limit value channel 1 8000h
130 0 Function number channel 2 50h*
1 Function option channel 2 00h
2, 3 Upper limit value channel 2 7FFFh
4, 5 Lower limit value channel 2 8000h
131 0 Function number channel 3 50h*
1 Function option channel 3 00h
2, 3 Upper limit value channel 3 7FFFh
4, 5 Lower limit value channel 3 8000h
*)
with 2 channel operation FFh
