Manual VIPA System SLIO Chapter 5 Analog Output
HB300E - SM - Rev. 09/38 5-7
Byte Meaning Default
0 Bit 0: error in module
Bit 1: reserved
Bit 2: external error
Bit 3: channel error
Bit 4: external auxiliary supply missing
Bit 5, 6: reserved
Bit 7: wrong parameter in module
00h
1 Bit 3 ... 0: module class
0101 analog module
Bit 4: channel information present
Bit 7 ... 5: reserved
15h
2, 3 reserved 00h
4 Bit 6 ... 0: channel type
70h: digital input
71h: analog input
72h: digital output
73h: analog output
74h: analog in-/output
Bit 7: reserved
73h
5 Number of diagnostic output bits per channel 08h
6 Number of similar channels of a module 02h
7 Bit 0: channel error channel 0
Bit 1: channel error channel 1
Bit 7 ... 2: reserved
00h
8 Channel-specific error channel 0:
Bit 0: configuring/parameter assignment error
Bit 2 ... 1: reserved
Bit 3: short-circuit to ground
Bit 7 ... 4: reserved
00h
9 Channel-specific error channel 1:
Bit 0: configuring/parameter assignment error
Bit 2 ... 1: reserved
Bit 3: short-circuit to ground
Bit 7 ... 4: reserved
00h
10
...
15
Bit 7 ... 0: reserved 00h
Diagnostic data
