Chapter 5 Analog Output Manual VIPA System SLIO
5-8 HB300E - SM - Rev. 09/38
Data VIPA 032-1BB30
Number of inputs 2 (single-ended)
Power supply DC 24V via power module
Input range 0 ... 10V
Current consumption
5V
24V
80mA
35mA
Burden min. 5kΩ (short-circuit proof)
Accuracy 0.2%
(relating to operational limit at 25°C)
Resolution 12bit (incl. overrange area)
Conversion time 2ms all channels
Isolation 500Veff (field voltage to the bus)
Module ID 0501 25D8
Bit-width in the process image Output: 2x16bit data
Configurable yes
Technical data
