Chapter 11 Integrated OBs SFBs SFCs Manual VIPA CPU 21x
11-6 HB103E - Rev. 05/45
VIPA specific SFCs
The integrated SFCs are programmed in Assembler and for this they have
a fast processing time. They do not occupy space in the internal program
memory.
The integrated blocks are called in the user application.
The following pages show the VIPA specific blocks that may be called for
special functions in the control application.
For not every SFC is integrated in every CPU family, this table shows the
assignment between SFC and CPU.
The first number specifies the CPU family, e.g.11x means: CPU 11x from
System 100V.
SFC Label Description 11x 21x 31x 51x
SFC 216 SER_CFG RS232C Parameterization
✓
✓
SFC 217 SER_SND RS232C Send
✓
✓
SFC 218 SER_RCV RS232C Receive
✓
✓
SFC 219 CAN_TLGR CAN telegram
✓
✓
SFC 220 MMC_CR_F Create file on MMC
✓
✓ ✓ ✓
SFC 221 MMC_RD_F Read file on MMC
✓
✓ ✓ ✓
SFC 222 MMC_WR_F Write to file on MMC
✓
✓ ✓ ✓
SFC 223 PWM Parameterize pulse duration modulation
✓
SFC 224 HSC Parameterize high-speed counter
✓
SFC 225 HF_PWM Parameterize HF pulse duration modulation (
up to 50kHz )
✓
SFC 227 TD_PRM Parameterization for TD200 communication
✓
✓ ✓ ✓
SFC 228 RW_Kachel Read/write page frame
✓ ✓ ✓
SFC 230 Send Send via page frame (page frame comm.)
✓ ✓ ✓
SFC 231 Receive Receive via page frame (page frame comm.)
✓ ✓ ✓
SFC 232 Fetch Fetch via page frame (page frame comm.)
✓ ✓ ✓
SFC 233 Control Control for page frame communication
✓ ✓ ✓
SFC 234 Reset Reset for page frame communication
✓ ✓ ✓
SFC 235 Synchron Synchron for page frame communication
✓ ✓ ✓
SFC 236 Send_All Send_All via page frame (page frame comm.)
✓ ✓ ✓
SFC 237 Recv_All Receive_All via page frame (page frame com.)
✓ ✓ ✓
SFC 238 Control1 Control for page frame communication
with Type ANZW: pointer and parameter IND.
✓ ✓ ✓
For a better overview, in the following every SFC repeats an extract of this
assignment table.
The next pages describe the VIPA specific SFCs.
General
Assignment table
SFC ←
←←
←→
→→
→ CPU
