22--wwaayy rreemmoottee ccoonnttrrooll ddiiaaggrraamm
1. Arm/Disarm Indicator (Orange)
2. Receive/Transmit Indicator (Green)
3. Auxiliary Indicator (Yellow)
4. Siren Indicator (Red)
5. Arm Button
6. Disarm Button
7. Panic Button (Orange)
8. Auxiliary Channel Button
1
2
3
4
5
6
78
