18 © 1998 Directed Electronics, Inc. Vista, CA
N438 7/98
OPERATING-SETTINGS LEARN ROUTINE™
Many of the operating settings of this unit are programmable. They can be changed whenever necessary through
a computer-based Learn Routine
™
. In order to access Learn Routine
™
, the jumper underneath the sliding door on
the module must be in the learn position (see page 9). The Valet
®
/Program push-button switch, plugged into the
blue port is used together with a programmed transmitter to change the settings. To program settings remember:
Door, Key, Choose, Transmit and Release.
1. Door Open a door. Either the H1/5 green or the H1/7 violet door trigger
wire must be connected for the control unit to “see” an open door.
2. Key Turn the ignition on and then back off. The H1/9 yellow
switched ignition input must be connected.
3. Choose Within 15 seconds, press and release the Valet
®
/Program button
the number of times corresponding to the number of the
desired feature (see the chart below). The one chirp settings
below are the factory default settings, except where indicated by
bold text.
Feature Number One-chirp setting Two-chirp setting
1 Active arming Passive arming
2 Arm/disarm chirps on Arm/disarm chirps off
3 Ignition-controlled door locks Standard door locks
4 Active locking only Passive locking
5 Panic with ignition on No panic with ignition on
6 0.8 second door lock pulses 3.5 second door lock pulses
7 Forced passive arming on Forced passive arming off
8 Automatic engine disable on Automatic engine disable off
9 VRS
®
enabled VRS
®
disabled
10 Code Hopping™ on Code Hopping
™
off
11 Siren Horn honk
12 Standard unlock pulse Double unlock pulse
