Viper AS7690T-US User Manual

INSTRUCTION FOR USE
ENGLISH
9
WORKING MODE DESCRIPTION
HOW TO OPERATE
DISPLAY
DESCRIPTION
Normal mode
Key (42) on
One button start (49) on
1: Hour meter point does not flash.
2: The brush arrow does not rotate.
3: The fan does not flash.
4: The tap water does not flash.
5: The actuator puts down to the first level pressure.
Key (42) on
One button start (49) on
Safety switch (35) on
1: Hour meter point flashes.
2: The brush arrow rotates.
3: The fan flashes. (Four blades）
4: The tap water flashes.
Silent mode
Key (42) on
One button start (49) on
1: Hour meter point does not flash.
2: The brush arrow does not rotate.
3: The fan does not flash.
4: The tap water does not flash.
Key (42) on
One button start (49) on
Press vacuum system adjustment but-
ton (50) on for 1 second
Safety switch (35) on
1: Hour meter point flashes.
2: The brush arrow rotates.
3: The fan flashes. (Three blades）
4: The tap water flashes.
Off mode
Safety switch (35) off
One button start (49) off
Key (42) on
1：Hour meter point does not flash .
2：All panel button closure.
（The vacuum motor delays 12 seconds to stop .)
3：The brush head puts up to the highest position.
Key (42) off
1. The power cut off.
2. The display is off.
Note: After turning off the one button start (49), wait un-
til the brush head raises to the full up position, before
turning off the key (42).
