ENGLISH USER MANUAL
10
Use only low-foam and non-flammable detergents suitable for ride-on scrubber
applications.
Each time when you need to fill the solution tank, always empty and clean the
recovery tank by removing the drain hose plug(C1). After each use, unscrew the drain
cap (D1) to drain solution tank.
CHECKING THE SPEED DRIVER
1. Sit on seat (A1) of the machine.
2. Turn on the key switch (E5).
3. Lightly depress the driver pedal (C6) to move and release it checking the machine forward or
stop.
4. For more security, you need to press the Emergency-stop button (A15) to make machine
sudden halt to check the button is work, when you use the machine for the first time. Release
it by turning.
5. If the drive motor error indicator (E4) is on, you must pay more attention. see ERROR
INFORMATION
The gradient in the direction of travel should not exceed (10) %.
The brake of drive motor is active when the machine is running normally, that is the
brake bracket is close to motor main body. When machine is on package \un-package
or machine error and some special situations, brake bracket will pull out, and use
washer to choke，so the machine can move by hand pushing.
MACHINE OPERATION
Do not operate machine unless you have professional training. You have read and
understand this manual before operate machine.
1. You should sit on the seat of the machine when you operate it.
2. Lower squeegee assembly to the floor.
Make sure to raise the squeegee before the machine is moving backward, or machine
stops and LED screen displays ERR-01.
3. Lower the brush head to the floor.
You’d better to turn off the brush motor button before raising the brush to prevent
water throw out. You’d better to raise the brush head before the machine is reverse.
Don’t make brushes work in a same place for a long time to damage the floor.
To Next Page
