ENGLISH USER MANUAL
12
2. Turn machine off (E5).
3. Plug approved charger into grounded wall outlet. Open transparent cover (A9), and then
connect the charging cable to the machine socket (F1).
4. The charger will automatically begin to charge the batteries.
5. Check that the battery charging is complete. Charging indicator (F2) is green.
6. Upon completion of charging, first unplug the charger from the wall outlet, and then
disconnect the charger from the machine.
7. Storage the charging cable in the below chair (C3).
Check battery connections for wear and loose terminals. Replace if necessary.
When charging the machine, please do not use machine.
Battery mode setting up method of the charger.
Do not to set charger unless you have professional training.
DIPSWITCH: SW1 (ONLY FOR)
MACHINE STORAGE
If the machine is not going to be used for more than 30 days, please proceed with the following
actions:
1. Perform the “After each use” maintenance procedures. (See Maintenance section).
2. Raise brush and squeegee.
3. Store machine in a clean, dry and no slope place. If storage in an area that may reach freezing
temperatures, be sure to drain all fluids from the machine prior to storage. Any damage caused
by freezing will void the warranty.
MAINTENANCE
Maintenance procedures must be performed with the machine turned off and battery
charger cable disconnected.
DP1 DP2 CHARGING CURVE
ON OFF IUIa-ACD for Lead-acid (Wet) batteries
OFF OFF IUIa-GEL for Gel batteries of Exide-Sonnenschein
OFF ON IUU0-GEL for HAZE Gel and AGM batteries of other manufacturers
ON ON IUIUa-AGM for Discover AGM batteries
