Viper AS850R User Manual

USE
R MANUAL
EN
GLISH
13
A
ll maintenance procedures must be performed by qualified personnel, or by authorized
Service Center. This Manual describes only the most common maintenance. For
additional maintenance procedures, contact your local Service Center.
SC
HEDULED MAINTENANCE TABLE
Procedure After each use Weekly Every six mouths Annually
Battery charging
Clean Squeegee
Clean Brush/Pad
Clean Tank and vacuum grid
with float, cover gasket
check
Squeegee blade check and
replacement
Recovery filter cleaning
Clean solution pipe filter
Screw and nut tightening
check
（1）
lubricate rotary parts （1）
Brush/Pad-holder motor
carbon brush check or
replacement
（2）
Vacuum system motor
carbon brush check or
replacement
（2）
Drive motor check or
replacement （2）
(1) And
after the first 8 working hours.
(2) This maintenance procedure must be performed by an authorized Service Center
.
SQUEEGEE CLEAN AND BLADE REPLACEMENT
F
or optimal performance, the squeegee blades must be clean, dry and undamaged. If
damaged, replace it.
1. Unscrew the knob (B2) to remove squeegee.
2. Unscrew the left and right knob to relax the front clamp, replace the front blade.
3. Disengage the retainers (B4) and remove the rear clamp, replace the rear blade.
4. Install the blades in the reverse order to removal
.
5. I
nstall the squeegee to screw the knob (B2).
