USER MANUAL ENGLISH
15
Parameter
Water Flow
Indication LEDs
Solenoid Valve
Aerage Water Flow
(L/min)
1 LED ON 2S ON 4S OFF 1.4
2 LEDs ON 3S ON 3S OFF 2.1
3 LEDs ON 4S ON 2S OFF 2.8
4 LEDs ON ON 4.2
Model AS710R AS850R
Machine length/width/height
1580*760*1230 1580*890*1230
Solution tank capacity
120L 120L
Recovery tank capacity
120L 120L
Rear wheels diameter
300MM 300MM
Brush motor power
2x300W 2x300W
Vacuum motor power
500W 500W
Drive motor power
500W 500W
Max. driver speed
6km/h 6km/h
Sound level
69dB(A) 69dB(A)
Batteries length/width/height
4x245AH(20hours)
4x245AH(20hours)
Batteries spec
241*168*300
241*168*300
Vaccum capacity
1800mm H2O 1800mm H2O
Cleaning productivity
4413sq.m/h 5130sq.m/h
Squeegee width
940MM 1060MM
Brush diameter
2x355MM 2x406MM
Brush rpm
204rpm/min 204rpm/min
Charger
24V 25A 24V 25A
Machine weight
225KG 230KG
Machine weight(gross)
400KG 440KG
Carton spec 1730*810*1410 1730*900*1410
USB charger spec 5V, 0.8A 5V, 0.8A
Gradient 10% 10%
Brush deck width 740mm 850mm
