USE
R MANUAL
EN
GLISH
7
B
atteries emit hydrogen. Explosion or fire can result from hydrogen. Keep sparks and
open flames away! It is recommended to push the button (C2) to turn recovery tank open
before charging.
Flammable materials can cause an explosion or fire. Do not use flammable materials in
tanks.
Flammable materials or reactive metals can cause an explosion or fire. Do not pick up by
hand.
WARNING It indicates a potential risk of injury or dangerous situation with risk
of death for the operator.
NOTED It indicates a remark related to important reminding or useful
functions.
MAC
HINE SET UP & INSTALLATION
UNPACKING MACHINE
Be
sure and check packing carton for any damage. Report immediately any damage to carrier.
Check contents of package to ensure that the following items are included:
1. Machine
2. Squeegee assembly
3. Brush assembly (x2)
4. User manual
5. Battery charger (If equipped)
6. Batteries (x4) (If equipped)
7. Connecting wire for battery and charger (If equipped)
8. Warning lamp (If equipped)
9. Bumper bracket (If equipped)
BATTERY CONNECTIONS
1. T
urn off the key switch (E5).
2. Turn the seat (A1) open, push board (C2) and turn recovery tank (A3) open. If machine does
not include batteries. Fit batteries suitable to your requirements.
After selecting batteries, please choose WET or GEL mode with toggle switch on the
back
of
PCB, as shown in the figure below.
