Viper FANG 20T Owner's Manual

DIA
NO
PART
NUMBER
DESCRIPTION
NO
REQ'D
1
VF81713
BUSHING 2
2 VF14122 WASHER,PLAIN,M10XM20X2 2
3
VF14121
SCREW,M10X65 2
4
VF13502
NUT,LOCK,M6 10
5
GT13032
WASHER,PLAIN,M6 2
6
VF81781
DIODE,400V 3
7
VF81726A
SOLENOID,24V 2
8
VF81734
BREAKER,CIRCUIT,35 AMP 2
9
VF83149
LABEL,CIRCUIT BREAKER 1
10
VF82108
HOUSING,CONTROL 1
11
VF14078
SCREW,M3X10 6
12
VA50477
WASHER,PLAIN,M3XM10X1 6
13 VF81718
LIGHTS,BATTERY CAPACITY 1
14
VF13495
SCREW,M6X16 4
15
VF82313
GASKET 1
16
VF81719
SPACER 6
17
VF82102A
PANEL,SWITCH 1
18
VF82103A
LABEL,SWITCH 1
19
VF81721
SWITCH,LIGHTED ROCKER 3
20
VF14200
SCREW,M6X16 12
21
VF81709
PIN,HANDLE LOCK 2
22
VF81716
SPRING 1
23
VF81710
PIN,HANDLE ADJUSTMENT 2
24
VF81744A
STRAIN RELIEF,CORD 1
25
VF82312
GASKET 1
26
VF82085
SERIAL TAG 1
27
GV40239
COVER 1
28
VF83148
LABEL,CIRCUIT BREAKER 1
29
VF82303A
PANEL,CONTROL HOUSING 1
30
VF81703
BATTERY CAPACITY,CONTROL BOARD 1
31
VF82107BD
HANDLE,RIGHT 1
32
VF81711
BOLT,SHOULDER M8XM15XM6 2
33
VF81712
SPRING 1
34
VF13491
SCREW,M4X12 1
35
VF13514A
WASHER,PLAIN,M8XM16.5X1 2
36
VF82106BD
HANDLE,LEFT 1
37 VF14212
SCREW,M3X25 2
38 VF13511
WASHER,TEETH,M3 2
39 VF44203
SWITCH ASSEMBLY 1
40 VF83141
BRACKET,SWITCH 1
41 VV13652
NUT,LOCK,M3 2
42 VF81714
TUBE,HANDLE,ADJUSTMENT 1
43 VF82153
SWITCH,KEY 1
44 VF82160
LABEL,KEY SWITCH 1
45 VF99012
BREAKER,CIRCUIT,12 AMP 1
FANG20 - CONTROL HOUSING
12
