Viper FANG 20T Owner's Manual

4
MACHINE COMPONENTS
1. Vacuum ON/OFF switch
2. Brush ON/OFF switch
3. Battery level meter
4. Solution ON/OFF switch
5. Solution control knob
6. Recovery tank drain hose
7. Squeegee assembly
8. Brush lift foot pedal
9. Solution tank level sight tube
10. Console adjustment levers
11. Rear solution fill
12. Circuit breakers
13. Squeegee lift lever
14. Control housing
15. Solution tank
16. Transport wheels
17. Scrub head
18. Scrub head skirt
19.
Protective rollers
20. Front sol
ution fill
21. Recovery tank
22. Recovery tank lid
23. Operating triggers
24. Main power ON/OFF switch
25. Reverse switch
26. Speed control knob
20
21
22
23
14
13
11
15
16
1718
19
13
2 3 4
12
11
10
9
8
5
6
1
7
24
4
3
26
25
1
12
2
