19 / 120INST-007080 / E eco-CONTROL EC200 2.0
OPERATION
4.1.3
2-component dispenser connection
Illustrated with non-self-levelling liquid (material/high viscosity material)
1. Motor 1, 2. Motor 2, 4. Dispensing Pressure A, 5. Dispensing Pressure B,
16. Pressure OUT
Illustrated with self-levelling liquid (low viscosity material)
1. Motor 1, 2. Motor 2, 4. Dispensing Pressure A, 5. Dispensing Pressure B
AB
12
5
4
16
Fig. 6
AB
5
4
12
Fig. 7
