for battery protection.
15. Maintenance
Bypass Switch
It is Make Before Breaker type. Only an Qualified
technician is permitted to use it.
16. Input Breaker
It is a 100A/300Vac No Fuse Breaker.
17. Terminal Block
(SINGLE PHASE)
This terminal to be connected with input, output and
additional battery banks for longer backup time purpose.
Only a qualified technician is permitted to proceed the
installation.
18. Terminal Block (3-
PHASE)
This terminal to be connected with input and output. Only
a qualified technician is permitted to proceed the
installation.
19. Terminal Block (3-
PHASE)
This terminal to be connected with additional battery
banks for longer backup time purpose. Only a qualified
technician is permitted to proceed the installation.
