INSTALLATION
1. FIT BRACKETS TO WALL Position brackets over load-bearing studs and use appropriate
screws to fix brackets to wall or ceiling. Ensure they are level.
NOTE: Do not position the top of bracket closer than 140mm to cornice.
2. FIT LOUDSPEAKERS TO MOUNTS Lower loudspeakers onto brackets as shown.
